◆ LFP battery system, system level multiple maintenance design, safe and reliable
◆ Modular design, flexible configuration, and easy expansion
◆ Long cycle life, slow attenuation, and excellent performance
◆ Simple operation and maintenance, saving time, effort, and money
| Type |
HB50K/100K |
| Battery Type |
LiFePO4@GF |
| Energy |
98.88KWh |
| Nominal Capacity |
206Ah |
| Rated Battery Voltage |
480V |
| Operating Voltage Range |
375V~540V |
| Max Charging Current |
103A |
| Max Discharge Current |
103A |
| Storage Temperature Range |
-20℃~ 45℃ & -4℉~113℉ |
| Operating Temperature Range |
-20℃~ 55℃ & -4℉~131℉ |
| Operating RH |
10%~90% |
| Storage and Transportation RH |
5%~95% |
| Working Altitude |
≤3000m |
| Cycle Life |
3500cycles≥80%DOD@25℃ |
| Communication Type |
CAN/RS485 |
| L*W*H（Size） |
830*800*2100mm |
| Net Weight |
≈ 900kg |
